Stuck on the green Xbox boot logo with E106 or E200? It's a hardware fault — usually storage or APU-side.
The Xbox Series X green screen of death isn't a software hang. It's an early-boot hardware error, usually surfaced with code E106 or E200 in the system info panel. The console can't complete the SoC handshake with internal storage or has lost a critical voltage rail, so it freezes on the boot logo.
Reinstalling the OS won't fix it — the console can't get far enough through boot to run the installer. We diagnose at the rail and chip level: NVMe storage health, the APU power-delivery network, and the early-boot SPI flash. Fix scope ranges from a reflowed storage chip to a recap of failed capacitors on the SoC rail.
Microsoft's own troubleshooter loops you through factory resets that can't run on a console that won't boot. We identify the failing component.
If it's a power-rail capacitor or APU-side fault, we fix it under microscope rather than writing the console off.
If the APU itself has failed, we tell you. Some E200 cases aren't economic to repair, and we'd rather you know than spend £100 on a guess.
Typical labour range for green-screen-of-death repair (parts on top at supplier cost):
You get a firm written quote after free photo quote, and no chargeable work starts without your approval. No fix, no fee on every repair — you only pay for work actually done. Parts at supplier cost — you see the invoice. See full pricing structure.
E106 typically points to internal storage failing the early-boot integrity check — the SoC can't talk to the NVMe. E200 is broader: a generic boot-block failure that can be storage, APU power delivery or corrupted SPI boot flash. The error code narrows the search but doesn't isolate the part — we still need to probe the board to confirm.
If you can reach the troubleshooter, sometimes yes. But true GSOD locks you on the green logo before the recovery menu loads, so the offline system update flow can't run. At that point it's hardware.
£65–£120 depending on the fault. A capacitor recap on the APU rail is at the lower end. Storage repair or replacement, where the NVMe chip itself has failed, sits at the upper end. Free photo quote and a firm written price after diagnosis.
Cloud saves come back when the console boots again. Locally-stored games re-download. Internal storage is preserved where possible during repair, so often nothing is lost — but if the NVMe itself has failed, the storage is gone with it.
Typically 3–7 working days from arrival. Storage-chip work can run a day or two longer because of bench-test time.
No. Green screen happens before the disc drive is even queried. If you also have a disc-read issue, that's a separate repair — see /xbox-disc-drive-repair.html.
Yes, the same E106/E200 codes appear on Series S and all-digital Series X. The repair scope is similar; cost is usually a touch lower on Series S because of the simpler power-delivery layout.
Send a couple of photos via the contact form or WhatsApp and you’ll have a firm quote back the same day.
